The o450 analog motor driven roller with 24 V or 48 V connection is a real pacemaker for your application and accelerates up to a rated speed of 1.5 m/s with a rated torque of 1.35 Nm. The innovative permanent magnet motor represents a new type of drive concept. It can be used to successfully implement roller conveyors, accumulating roller conveyors, and dynamic sorters.
Highlights
– The very high efficiency minimizes energy costs
– External rotor – based on the Vernier principle – ensures a low-noise transport of loads
– Brushless permanent magnet motor with high performance ensures significantly faster goods transportation
– Few variants and tube lengths from 345 … 1500 mm allow direct integration into the conveyor line
– They can be integrated into the system using standard plug & play control units
Technical data
– Rated torque: 1.35 Nm
– Max. torque: 5.0 Nm
– Rated speed: 1.5 m/s
– Max. speed: 3.0 m/s
– Tube diameter: 50 mm
– Tube installation lengths: 345 … 1500 mm
